Plus it was possibly the hardest form of brass in the universe.
The JB Weld didn't take though as a 2mm ring just wasn't enough surface to adhere to and take the pressure of grinding down a countersink cone. Perfection Nickel-plated brass though, but they won't be visible so didn't matter if paint didn't take, but a quick rasping on the mating surface got rid of the nickel there ready for the JB Weld.
Anesidora us forums mod#
The Mod Gods were merciful and I found some perfect spacers: M4 tight through holes (4.1mm) and 8mm diameter. These spacers would also serve as proper alignment feet for the Barrow heatsink ring given it's just 8mm through holes and slides around the screws as you tighten up. The idea at this point was to JB Weld spacers to the inside surface and give me more material to form the countersink. I'm using 1.5mm aluminium and the countersink M4 head is 2.3-2.5mm, so I wasn't sure if I could just slap a countersink into the mounting bracket given I'm missing almost 1mm of material to cut into. What I've not shown you here is a small failure. But the plan is to use countersink screws and get them flush with the mount. The head height for those screws though is 2.3mm so of course they're not going to work. As a result I'm using standard dome head M4 screws to bolt everything together. Now at this point I'm still just test fitting for viability. But 1mm in this build is acres of space so I'm not too concerned right now. If the mount is flush then the glass will press on the pump and we'll get vibration and noise. The pump mount is almost flush with the case tabs that hold the side panel mounts.
Now, in a perfect world the entire pump assembly would fit within that 43mm operating space so I can put the side panels back on with no further mods, but if need be I can put in a 1mm spacer to just edge the panels out without issue. Hot damn that's tight, but it's not actually touching the Titan. So far so good, but there's supposed to be a computer in there. and then fold that bottom tab into place. Quick assembly to ensure my mounting holes are correct. But I'm stoked to get the end result that good with just a step drill, coping saw and a crap wrist Believe it or not I actually cut this by hand! So I grabbed one and redesigned my mount. Could I combine then the actual heatsink portion and mounting bracket? That would save a lot of space. But then I noticed Barrow take a slightly different approach.īarrow's heatsinks are actually in 2 parts: a chunky piece of aluminium which does the actual heatsinking and a thin body ring. Same deal with the EK heatsink easy enough to strip the anodising off the aluminium, but then it would need recolouring. Plus, I didn't fancy the idea of getting nickel everywhere from cutting and filing, and I know I'd just want to strip it down and replate to keep things tidy. Nice, but then put 1.5mm back on for my mounting bracket and we're up to the limit again. Because Alphacool use a very thin thermal pad, removing the fins would reduce the heatsink to 19mm. The first plan was to just chop the fins off my Alphacool heatsink. I've already discussed modding the Aquacomputer DDC top to have a side feed and using a custom stainless steel plate to seal off the top feed, so that keeps the top down to 20mm, but it was the heatsink that was the major issue. What that doesn't factor in though are the fins on the bottom of the DDC heatsink, which add 5mm, and DDC tops traditionally are fed from the top. Factor in some manufacturing tolerance and the combined pump+top is 42mm tall. DDC heatsink bodies are on average 20mm tall and my choice of pump top is a further 20mm. I didn't cover in this particular log my pump mounting issues ( but detailed here if you're interested), but I'm very happy to say a significant step has been made in resolving it: the DDC is finally in!Īfter all the toing and froing regarding measurements and poor accuracy, I confirmed that the distance from the edge of the GTX Titan and the glass side panel gave me an operating width of 43mm.
2018 wasn't the most fantastic year so many things were shelved, delayed and ignored but work does continue (albeit very slowly) and I thought I'd share some success with you.
